Descripción
The fischer SXR-FUS frame fixing is a high quality Nylon cleat with pre-assembled fischer hex head screw and built-in washer. Thanks to the special dowel geometry, the SXR can be used on solid and perforated materials. Due to the low anchoring depth of only 50 mm, the frame fixing can be processed particularly economically, especially in the multiple fixings of non-load-bearing systems. The fischer SXR-FUS frame fixing with hexagon head screw and built-in washer is especially recommended for fixing metal structures.
CHARACTERISTICS
- The shallow anchoring depth saves time and costs.
- ETA evaluation in concrete and masonry.
- The plug expands in solid materials.
- In perforated materials, the plug is anchored in the hole.
- With the previously mounted security screw with hexagonal head and built-in washer.
ADVANTAGES
- The special function allows it to be used in solid and hollow building materials with an anchoring depth of only 50 mm, ensuring economical fastening.
- The ETA approval covers the use in a range of solid and hollow construction materials, and guarantees secure fixation.
- The specially developed combination of connectors and screws ensures optimal handling. The connector has a noticeable handle, which makes installation more favorable.
APPLICATIONS
- Facade, roof and roof structures made of wood and metal
- Windows
- Gates and doors
- Wardrobes
- kitchen hanging cabinets
- Squared timbers
- Beams
- television furniture
- Wall coverings
- metal angle
- Metal supports
- cable ducts
- cable ducts
CONSTRUCTION MATERIALS
- Approved for:
- Concrete ≧ C12/15
- Vertical perforated brick
- Hollow lightweight concrete blocks
- Perforated sandstone brick
- Solid sandstone brick
- Aerated concrete
- Solid block made of lightweight concrete and standard weight concrete
- Solid brick
- Thermal insulation blocks
- Also suitable for:
- Natural stone with dense structure
- Solid panel made of plaster
